Send InquiryPOLYCAB - 4 Core X 6 sq.mm. 1.1kV IS:694 Copper Flexible Cable
Price 399.0 INR/ Meter
POLYCAB - 4 Core X 6 sq.mm. 1.1kV IS:694 Copper Flexible Cable Specification
- Conductor Type
- Flexible, multi-stranded
- Connector Type
- Stripped cable, customizable ends
- No Of Core
- 4 Core
- Temperature
- -15C to +70C (operating temperature range)
- Cable Length
- 100 meters (typical)
- Product Type
- Flexible Copper Cable
- Material
- Copper Conductor with PVC Insulation
- Function
- Electric power transmission and distribution
- Usage
- Industrial wiring, panel internal wiring, and heavy-duty electrical installations
- Voltage Surge
- Upto 1.1 kV
- Frequency (MHz)
- 50 Hz
- Rated Voltage
- 1100 V (1.1 kV)
- Rated Current
- 33 Amps (Approx., varies by installation condition)
- Cable Capacity
- Suitable for high load applications
- Insulation Material
- PVC, Type A to IS:5831
- Conductor Material
- High Purity Annealed Copper
- Length
- Standard coil lengths: 100 meters (other lengths available on order)
- Size
- 6 sq.mm. cross-sectional area
- Color
- Black sheath, core colors: Red, Yellow, Blue, Black
- Diameter
- Approx. 7.5 mm (overall diameter)
- Application
- Control panels, machinery, industrial and commercial electrical applications
- Standard
- IS:694
- Weight
- Approx. 93 kg/km
- Conductor Stranding
- Class 5 (flexible conductor)
- Packing Type
- Coil/roll packaging, shrink wrapped
- Insulation Thickness
- 0.8 mm (nominal)
- Resistance at 20C
- 3.08 Ohm/km (maximum)
- Outer Sheath Thickness
- 1.0 mm (nominal)
- Flame Retardant
- Yes, flame retardant PVC as per IS:5831
- Suitable Standards
- IS:694, IEC 60227
- Test Voltage
- 3.0 kV AC for 5 minutes
- Sheath Material
- PVC (Polyvinyl Chloride)
- Elongation
- Minimum 20% (for copper conductor)
- Tensile Strength
- Minimum 15 N/mm2 (for copper conductor)
